Designed to meet the most current sterilization standards ANSI/AAMI ST55 ensuring highest sterilization levels and highest quality constructions to ensure longevity.
FEATURES
- Fast Cycles – Fast cycle times for wrapped instruments, complete cycle, including drying.
- Optimal chamber capacity – More than 75% chamber capacity with 5 extra-long trays
- Convenient loading – Convenient and easy loading with door opening to 110°
- Advanced documentation – A variety of documentation and traceability options and barcodes.
- User-friendly touchpad control panel – Displays programs, cycles times, water levels and more.
- Overall Dimensions (DxWxH)
- T-Edge 10: 21.1″ x 18.89” x 19.7”
- T-Edge 11: 21.1″ x 19.68” x 19.68”
- Chamber Volume
- T-Edge 10: 6 Gal / 23 Liters
- T-Edge 11: 7 Gal / 27 Liters
- Chamber Size
- T-Edge 10: 18” x 10” diameter
- T-Edge 11: 18” x 11” diameter
- Tray Capacity – 5 Trays
- Standard Cassette Capacity
- T-Edge 10: 3 Full + 3 Half
- T-Edge 11: 4 Full + 4 Half
- Connections – 1 Ethernet port, 4 USB ports, WiFi, integrated automatic water filling and drain connection
- Item Supplies – Drain tube, tray holder
- Voltage & Frequency
- 120V, Freq. 60Hz
- 230V, Freq. 60Hz
- Shipping Weight
- T-Edge 10: 117 lbs
- T-Edge 11: 124 lbs
